YH4
GRAND
VITARA
FRONT BRAKE 5B-11
TIGHTENING TORQUE SPECIFICATIONS
p
Tightening torque
N
.
m kg-m lb-ft
Brake caliper bleeder plug
(For SUMITOMO ELECTRIC brake caliper)
8.0 0.80 6.0
Brake caliper bleeder plug
(For TOKICO brake caliper)
8.5 0.85 6.5
Caliper pin bolt (For TOKICO brake caliper) 27 2.7 20.0
Caliper pin bolt (M10)
(For SUMITOMO ELECTRIC brake caliper)
50 5.0 36.5
Caliper pin bolt (M12)
(For SUMITOMO ELECTRIC brake caliper)
85 8.5 61.5
Flexible hose bolt 23 2.3 17.0
Brake carrier bolt 85 8.5 61.5
Wheel nut 100 10.0 72.5
REQUIRED SERVICE MATERIAL
MATERIALS
RECOMMENDED
SUZUKI PRODUCT
USE
Brake fluid
Indicated on reservoir
cap or described in owner’s
manual of vehicle
To fill master cylinder reservoir.
To clean and apply to inner parts of master
cylinder caliper and wheel cylinder when
they are disassembled.
To Next Page
