YH4
GRAND
VITARA
8D
WINDOWS, MIRRORS, SECURITY AND LOCKS 8D-1
GENERAL DESCRIPTION 8D- 2. . . . . . . . . . . . . .
Cautions in Servicing 8D- 2. . . . . . . . . . . . . . . . .
Symbols and Marks 8D- 2. . . . . . . . . . . . . . . . . . .
Wiring Color Symbols 8D- 2. . . . . . . . . . . . . . . . .
Abbreviations 8D- 2. . . . . . . . . . . . . . . . . . . . . . . .
Joint Connector 8D- 2. . . . . . . . . . . . . . . . . . . . . .
Fuse Box and Relay 8D- 2. . . . . . . . . . . . . . . . . .
Power Supply Diagram 8D- 2. . . . . . . . . . . . . . . .
Windshield Wiper and Washer 8D- 2. . . . . . . . .
Front Wiper and Washer 8D- 2. . . . . . . . . . . . .
Rear Wiper and Washer (If Equipped) 8D- 3.
Power Door Lock and Keyless Entry
(If Equipped) System 8D- 4. . . . . . . . . . . . . . . .
DIAGNOSIS 8D- 5. . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper and Washer 8D- 5. . . . . . . . .
Front Wiper and Washer 8D- 5. . . . . . . . . . . . .
Rear Wiper and Washer (If Equipped) 8D- 5.
Rear Window Defogger (If Equipped) 8D- 5. . .
Power Window Control System 8D- 5. . . . . . . . .
Power Door Lock System (If Keyless
Entry is not Equipped) 8D- 6. . . . . . . . . . . . . . .
Power Door Lock and Keyless Entry
System (If Keyless Entry is Equipped) 8D- 7. .
Power Door Mirror Control System 8D- 8. . . . . .
Door Mirror Heater (If Equipped) 8D- 8. . . . . . . .
Power Sliding Roof (If Equipped) 8D- 8. . . . . . .
Front Seat Heater (If Equipped) 8D- 8. . . . . . . .
ON-VEHICLE SERVICE 8D- 9. . . . . . . . . . . . . . . .
Windshield Wiper and Washer 8D- 9. . . . . . . . .
Front Wiper and Washer 8D- 9. . . . . . . . . . . . .
Rear Wiper and Washer (If Equipped) 8D-13.
Rear Window Defogger (If Equipped) 8D-16. . .
Power Window Control System 8D-18. . . . . . . . .
Power Door Lock System (If Keyless
Entry is not Equipped) 8D-20. . . . . . . . . . . . . . .
Power Door Lock and Keyless Entry
System (If Keyless Entry is Equipped) 8D-23. .
Power Door Mirror Control System 8D-30. . . . . .
Door Mirror Heater (If Equipped) 8D-31. . . . . . . .
Power Sliding Roof (If Equipped) 8D-32. . . . . . .
Front Seat Heater (If Equipped) 8D-33. . . . . . . .
SECTION 8D
WINDOWS, MIRRORS, SECURITY AND LOCKS
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System:
Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to “Air Bag System Components and Wiring Location View” under “Gener-
al Description” in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and “Service Precau-
tions” under “On-Vehicle Service” in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.
Technical service work must be started at least 90 seconds after the ignition switch is turned to the
“LOCK” position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
