YH4

GRAND

VITARA

1. Headlight leveling switch

2. Headlight leveling unit (actuator)

3. Headlight

4. Headlight leveling unit shaft

Switch

Position

Headlight beam

down angle

0 ———

1 0.624_

2 1.243_

3 1.867_

4 2.479_

LIGHTING SYSTEM 8B-3

HEADLIGHT WITH LEVELING SYSTEM (IF EQUIPPED)
