YH4
GRAND
VITARA
8D-8 WINDOWS, MIRRORS, SECURITY AND LOCKS
POWER DOOR MIRROR CONTROL SYSTEM
Trouble Possible cause Correction
All power mirrors do not
operate
“CIGAR” fuse blown (Hard Top Model)
“CIG” fuse blown (Canvas Top Model)
Power door mirror switch faulty
Wiring or grounding faulty
Replace fuse to check for short
Replace switch
Repair
One power mirror does
not operate
Power door mirror switch faulty
Actuator (power door mirror motor) faulty
Wiring or grounding faulty
Replace switch
Replace actuator
Repair
DOOR MIRROR HEATER (IF EQUIPPED)
Trouble Possible cause Correction
The surface of mirror is
not defrosted although
door mirror heater
switch is ON
“REAR DEFG” fuse blown (Hard Top Model)
“DEF” fuse blown (Canvas Top Model)
Door mirror heater switch faulty
Door mirror heater faulty
Wiring or grounding faulty
Replace fuse to check for short
Replace switch
Replace outside mirror
Repair
POWER SLIDING ROOF (IF EQUIPPED)
Trouble Possible cause Correction
Sliding roof does not
operate (sliding roof
motor runs OK)
Foreign object stuck in sliding roof rail
Misinstallation of sliding roof rail
Conflicts of sliding roof parts
Misinstallation of sliding roof drive cable
Remove or clean stuck object
Install correctly
Fix conflicts
Install correctly
Sliding roof does not
operate (sliding roof
motor does not run)
“SUN ROOF” fuse blown
Sliding roof switch faulty
Sliding roof motor ass’y faulty
Wiring or grounding faulty
Replace fuse to check for short
Replace switch
Replace motor
Repair
FRONT SEAT HEATER (IF EQUIPPED)
Trouble Possible cause Correction
Both seat back and
cushion do not become
hot although seat heater
switch is LO/HI position
“SEAT HTR” fuse blown (Hard Top Model)
“S/H” fuse blown (Canvas Top Model)
Seat heater switch faulty
Seat heater circuit in seat back and/or seat
cushion faulty
Wiring or grounding faulty
Replace fuse to check for short
Replace switch
Replace heater front back and/
or heater front cushion
Repair
Only seat back does not
become hot although seat
heater switch is HI
position
Seat heater circuit in seat back faulty
(Hard Top Model)
Seat heater circuit in seat back and/or seat
cushion faulty (Canvas Top Model)
Seat heater switch faulty
Wiring faulty
Replace heater front back
Replace heater front back
and/or heater front cushion
Replace switch
Repair
Only seat cushion does
not become hot although
seat heater switch is HI
position
Seat heater circuit in seat back and/or seat
cushion faulty (Hard Top Model)
Seat heater circuit in seat cushion
(Canvas Top Model)
Seat heater switch faulty
Wiring faulty
Replace heater front back
and/or heater front cushion
Replace heater front cushion
Replace switch
Repair
To Next Page
