MANUAL TRANSMISSION (TYPE 2) 7A1-5
TIGHTENING TORQUE SPECIFICATIONS
Fastening
p
ortion
Tightening torque
Fastening
ortion
N·m kg-m lb-ft
Transfer oil filler/level and drain plugs 23 2.3 17.0
Transmission oil filler/level and drain plugs 38 3.8 27.5
Control lever boot cover bolts 6 0.6 4.0
4WD switch 20 2.0 14.5
Back-up light switch 45 4.5 32.5
Control lever locating bolts 17 1.7 12.5
Transmission to engine bolts and nuts 85 8.5 61.5
Engine rear mounting bolts 50 5.0 36.5
Muffler to exhaust No. 2 pipe nuts 50 5.0 36.5
Universal joint flange bolts 50 5.0 36.5
REQUIRED SERVICE MATERIALS
MATERIAL
RECOMMENDED
SUZUKI PRODUCT
USE
Lithium grease
SUZUKI SUPER GREASE A
(99000-25010)
 Shift control lever
Thread lock cement
THREAD LOCK CEMENT
SUPER 1333B
(99000-32020)
 Shift control lever locating bolts
Sealant
SUZUKI BOND No. 1215
(99000-31110)
 Oil drain and filler/level plugs
