YH4
GRAND
VITARA
8C
INSTRUMENTATION/DRIVER INFORMATION 8C-1
GENERAL DESCRIPTION 8C- 2. . . . . . . . . . . . . .
Cautions in Servicing 8C- 2. . . . . . . . . . . . . . . . .
Symbols and Marks 8C- 2. . . . . . . . . . . . . . . . . . .
Wiring Color Symbols 8C- 2. . . . . . . . . . . . . . . . .
Abbreviations 8C- 2. . . . . . . . . . . . . . . . . . . . . . . .
Joint Connector 8C- 2. . . . . . . . . . . . . . . . . . . . . .
Fuse Box and Relay 8C- 2. . . . . . . . . . . . . . . . . .
Power Supply Diagram 8C- 2. . . . . . . . . . . . . . . .
Combination Meter 8C- 2. . . . . . . . . . . . . . . . . . .
DIAGNOSIS 8C- 4. . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer and VSS 8C- 4. . . . . . . . . . . . . . . .
Fuel Meter/Fuel Gauge Unit 8C- 4. . . . . . . . . . . .
Engine Coolant Temp. (ECT) Meter and
Sensor 8C- 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure Light 8C- 4. . . . . . . . . . . . . . . . . . . .
Brake and Parking Brake Warning
Light 8C- 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light Remainder Warning Buzzer 8C- 5. . . . . . .
Seat Belt Warning Light (If Equipped) 8C- 5. . .
Ignition Key Remainder Warning
Buzzer (If Equipped) 8C- 5. . . . . . . . . . . . . . . . .
Cigarette Lighter and Accessory Socket 8C- 5.
ON-VEHICLE SERVICE 8C- 6. . . . . . . . . . . . . . . .
Ignition (Main) Switch 8C- 6. . . . . . . . . . . . . . . . .
Combination Meter 8C- 7. . . . . . . . . . . . . . . . . . .
Speedometer and VSS 8C- 8. . . . . . . . . . . . . . . .
Fuel Meter/Fuel Gauge Unit 8C- 9. . . . . . . . . . . .
Engine Coolant Temp. (ECT) Meter and
Sensor 8C-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure Light 8C-11. . . . . . . . . . . . . . . . . . . .
Brake and Parking Brake Warning
Light 8C-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Key Remainder (If Equipped)/
Light Remainder Warning Buzzer 8C-12. . . . . .
Door Switch 8C-13. . . . . . . . . . . . . . . . . . . . . . . . .
Seat Belt Warning Light (If Equipped) 8C-13. . .
SECTION 8C
INSTRUMENTATION/DRIVER INFORMATION
WARNING:
For vehicles equipped with Supplemental Restraint (Air Bag) System
Service on and around the air bag system components or wiring must be performed only by an autho-
rized SUZUKI dealer. Refer to “Air Bag System Components and Wiring Location View” under “Gener-
al Description” in air bag system section in order to confirm whether you are performing service on
or near the air bag system components or wiring. Please observe all WARNINGS and “Service Precau-
tions” under “On-Vehicle Service” in air bag system section before performing service on or around
the air bag system components or wiring. Failure to follow WARNINGS could result in unintentional
activation of the system or could render the system inoperative. Either of these two conditions may
result in severe injury.
Technical service work must be started at least 90 seconds after the ignition switch is turned to the
“LOCK” position and the negative cable is disconnected from the battery. Otherwise, the system may
be activated by reserve energy in the Sensing and Diagnostic Module (SDM).
CONTENTS
