YH4
GRAND
VITARA
BODY SERVICE 9-23
1. Front bumper
2. Screws
3. Front bumper member
4. Side marker
FRONT BUMPER
NOTE:
Fasteners are important attaching parts in that they could affect the performance of vital components
and systems, and/or could result in major repair expense. They must be replaced with one of the same
part number or with an equivalent part if replacement becomes necessary.
Do not use a replacement part of lesser quality or substitute design. Torque values must be used as spe-
cified during reassembly to assure proper retention of these parts.
Before removing front bumper, remove fender lining and disconnect connector of side marker.
