Toyota 1HZ Repair Manual

IN-7
INTRODUCTION - Abbreviations Used in This Manual
ABBREVIATIONS USED IN THIS MANUAL
A/C Air Conditioner
ACV Air Control Valve
ACSD Automatic Cold Start Device
Approx. Approximately
A/T Automatic Transmission
BACS Boost and Altitude Compensation Stopper
BDC Bottom Dead Center
Ex. Except
FL Fusible Link
FIPG Formed in Place Gasket
HAC High Altitude Compensator
LH Left-Hand
LHD Left-Hand Drive
LST Load Sensing Timer
MP Multipurpose
M/T Manual Transmission
OHC Over Head Cam
O/S Oversized
PCS Power Control System
PCV Positive Crankcase Ventilation
RH Right-Hand
RHD Right-Hand Drive
SSM Special Service Materials
SST Special Service Tools
STD Standard
SW Switch
TDC Top Dead Center
U/S Undersize
w/ With
w/o Without

Toyota 1HZ Specifications

General

Fuel Type	Diesel
Maximum Power	96 kW (129 hp) at 3800 rpm
Firing Order	1-5-3-6-2-4
Aspiration	Naturally aspirated
Fuel System	Direct injection
Cooling System	Water-cooled
Displacement	4.2 L (4164 cc)
Maximum Torque	285 N·m (210 lb·ft) at 2200 rpm
Valvetrain	SOHC, 12 valves (2 per cylinder)
