Toyota 1HZ Repair Manual

CH-19
CHARGING SYSTEM - Alternator
6. INSTALL REAR END COVER
(a) Install the rear end cover with the three nuts.
(b) (PZJ, HZJ and HDJ)
Install the terminal insulator, condenser lead wire with
nut.
(c) (HZB and HDB)
Install the terminal insulator with the nut.
7. CHECK THAT ROTOR ROTATES SMOOTHLY
CH0845
CH0846
CH0836

Toyota 1HZ Specifications

General

Fuel Type	Diesel
Maximum Power	96 kW (129 hp) at 3800 rpm
Firing Order	1-5-3-6-2-4
Aspiration	Naturally aspirated
Fuel System	Direct injection
Cooling System	Water-cooled
Displacement	4.2 L (4164 cc)
Maximum Torque	285 N·m (210 lb·ft) at 2200 rpm
Valvetrain	SOHC, 12 valves (2 per cylinder)
