B-2 STANDARD BOLT TORQUE SPECIFICATIONS
STANDARD BOLT TORQUE SPECIFICATIONS
HOW TO DETERMINE BOLT STRENGTH
Mark Class Mark Class
No mark
4T
Grooved
6T
4T
5T
6T
7T
8T
9T
10T
11T
Stud bolt
Hexagon
head bolt
Hexagon
flange bolt
w/ washer
hexagon bolt
No mark
4T
No mark
4T
4
5
Bolt 6
head No. 7
8
9
10
11
Hexagon
head bolt
Two
protruding
lines
5T
Hexagon
flange bolt
w/ washer
hexagon bolt
Two
protruding
lines
6T
Welded bolt
4T
7T
8T
Four
protruding
lines
Three
protruding
lines
Hexagon
head bolt
Hexagon
head bolt

Toyota 1HZ Specifications

General

Fuel Type	Diesel
Maximum Power	96 kW (129 hp) at 3800 rpm
Firing Order	1-5-3-6-2-4
Aspiration	Naturally aspirated
Fuel System	Direct injection
Cooling System	Water-cooled
Displacement	4.2 L (4164 cc)
Maximum Torque	285 N·m (210 lb·ft) at 2200 rpm
Valvetrain	SOHC, 12 valves (2 per cylinder)
