LUBRICATION SYSTEM Replacement of Engine Oil and Oil Filter LU-7
(c) Apply clean engine oil to the gasket of a new oil filter.
(d) Lightly screw the oil filter into place, and tighten it
until the gasket contacts the seat.
(e) Using SST, tighten it additional 3/4 turn.
SST 09228-10001
3. FILL WITH ENGINE OIL
(a) Clean and install the oil drain plug with a new gasket.
Torque: 250 kg-cm (18 ft-lb, 25 N-m)
(b) Fill with new engine oil (API grade CC (ex. Europe),
CD or better and recommended viscosity oil).
Capacity (PZJ70, 73. 75):
Drain and refill
w/ Oil filter change
9.0 liters (9.5 US qts, 7.9 Imp. qts)
w/o Oil filter change
7.7 liters (8.1 US qts, 6.8 Imp. qts)
Dry fill 9.3 liters (9.8 US qts, 8.2 Imp. qts)
Capacity (HZJ70, 73, 75):
Drain and refill
w/ Oil filter change
9.5 liters (10.0 US qts, 8.4 Imp. qts)
w/o Oil filter change
8.2 liters (8.7 US qts, 7.2 Imp. qts)
Dry fill 9.8 liters (10.4 US qts, 8.6 Imp. qts)
Capacity (HZJ80 and HDJ80):
Drain and refill
w/ Oil filter change
9.3 liters (9.8 US qts, 8.1 Imp. qts)
w/o Oil filter change
8.0 liters (8.5 US qts, 7.0 Imp. qts)
Dry fill 9.6 liters (10.1 US qts, 8.4 Imp. qts)
Capacity (HZB30 and HDB30):
Drain and refill
w/ Oil filter change
9.8 liters (10.4 US qts, 8.6 Imp. qts)
w/o Oil filter change
8.5 liters (9.0 US qts, 7.5 Imp. qts)
Dry fill 10.1 liters (10.7 US qts, 8.9 Imp. qts)
(c) Reinstall the oil filler cap.
4. START ENGINE AND CHECK FOR LEAKS
5. RECHECK ENGINE OIL LEVEL (See page LU-5)
