Toyota 1HZ Repair Manual

FUEL SYSTEM - Injection Pump FU-35
(d) Remove the fuel cut solenoid, O-ring, spring, valve,
strainer and wave washer.
11. (w/TACHOMETER)
REMOVE PICKUP SENSOR
Remove the pickup sensor and O-ring.
12. REMOVE ADJUSTING LEVER
(a) Place the matchmarks on adjusting lever and shaft.
(b) Remove the nut, return spring guide, adjusting lever
and return spring.
13. REMOVE GOVERNOR COVER
(a) (w/HACand 1HD-T)
Remove the idle speed adjusting screw.
(b) Using a 5 mm hexagon wrench, remove the four bolts.

Toyota 1HZ Specifications

General

Fuel Type	Diesel
Maximum Power	96 kW (129 hp) at 3800 rpm
Firing Order	1-5-3-6-2-4
Aspiration	Naturally aspirated
Fuel System	Direct injection
Cooling System	Water-cooled
Displacement	4.2 L (4164 cc)
Maximum Torque	285 N·m (210 lb·ft) at 2200 rpm
Valvetrain	SOHC, 12 valves (2 per cylinder)
