Valve dimensions
Note
Inlet and exhaust valves must not be reworked. Only lapping-in
is permitted.
Dimension Inlet valve Exhaust valve
∅ a mm 33.85 ± 0.10 28.0 ± 0.1
∅ b mm 5.98 ± 0.01 5.96 ± 0.01
c mm 104.0 ± 0.2 101.9 ± 0.2
α ∠° 45 45
3.2 Removing and installing camshafts
Special tools and workshop equipment required
♦ Puller -T40039-
♦ Removal tool -T10352/1-
♦ Counterhold tool -T10355-
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
94 Rep. gr.15 - Cylinder head, valve gear
