Push hose -1- of filler neck onto connection on fuel tank -3-.
Position clamp -2- at assembly markings -arrows- using hose clip
pliers -VAS 6362- .
– Push on breather line -3- and engage securely.
♦ Connections for breather and fuel lines must engage audibly
when joined.
♦ Clip fuel lines onto fuel tank.
♦ Push connector onto fuel pump flange and clip wire onto fuel
tank.
♦ Ensure that fuel hose connections are tight.
Vehicles with lower protective cover
– Bolt protective cover to bottom of fuel tank .
3.3 Removing and installing fuel delivery
unit
Special tools and workshop equipment required
♦ Union nut tool -3217-
Removing
– Remove fuel tank ⇒ page 169 .
– Unclip fuel lines -2 and 3- from fuel delivery unit -1-.
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
172 Rep. gr.20 - Fuel supply system
