Marking on bearing shell for cylinder block:
Note
The marking on the cylinder block can be found engraved either
in the sump sealing surface or in the front end (gearbox side) of
the cylinder block.
Identification on cylinder block is allocated to upper bearing shell
(bearing shell for cylinder block).
– Note letters and identify colour code to be installed based on
table.
Marking on bearing shell for bearing cap:
Identification on crankshaft is allocated to lower bearing shell
(bearing shell for bearing cap).
– Note letters and identify colour code to be installed based on
table.
S = Black
R = Red
G = Yellow
B = Blue
W = White
4.3 Crankshaft dimensions
(Dimensions in mm)
Honing dimension
1)
Main journal ∅ Conrod journal ∅
Basic dimension
58.00
47.80
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
42 Rep. gr.13 - Crankshaft group
