– Attach lifting tackle -2024 A- as shown and lift from engine and
gearbox jack -VAS 6100- using workshop crane -V.A.G 1383
A- .
Caution
Use securing pins arrows on hooks and locking pins to avoid
damage to engine.
– Secure engine to engine and gearbox support -VAS 6095- .
1.3 Notes on installing
Special tools and workshop equipment required
♦ Vehicle diagnosis, testing and information system -VAS
5051B-
Procedure
Install in reverse order. In the process, note the following:
Caution
♦ Only a few millimetres of space are available between
plenum chamber and radiator/lock carrier for removing
and installing the engine. The engine must therefore be
guided carefully when raising and lowering.
♦ Raise and lower the engine slowly with the assistance of
a second mechanic.
♦ The workshop hoist -VAS 6100- must also be guided care‐
fully when raising and lowering the engine.
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
14 Rep. gr.10 - Removing and installing engine
