2.1 Overview of fitting locations
1 - Intake manifold pressure
sender -G71-
2 - Air mass meter -G70-
❑ Removing and installing
⇒ page 209 .
3 - Lambda probe -G39- and
Lambda probe heater -Z19-
4 - Vacuum pump
5 - High-pressure pump
❑ Removing and installing
⇒ page 226 .
6 - Engine speed sender -G28-
❑ Removing and installing
⇒ page 252 .
❑ 4.5 Nm
7 - Hall sender -G40-
8 - Activated charcoal filter sol‐
enoid valve 1 -N80-
9 - Intake air temperature
sender -G42-
10 - Throttle valve module -
J338-
❑ Throttle valve drive an‐
gle sender -G187- and
throttle valve drive angle
sender 2 -G188-
❑ Each time after remov‐
ing, installing or renew‐
ing throttle valve module
-J338- it must be re-
adapted to engine con‐
trol unit -J623- .
❑ Removing and installing ⇒ page 223 .
11 - Wiring harness to engine control unit
12 - Charge air pressure sender -G31-
❑ Removing and installing ⇒ page 186 .
13 - Coolant temperature sender -G62-
❑ Removing and installing ⇒ page 145 .
14 - Fuel pressure sender -G247-
❑ Removing and installing ⇒ page 222 .
15 - Oil pressure switch -F22-
16 - Knock sensor 1 -G61-
17 - Intake manifold flap potentiometer -G336-
18 - Ignition coils with final output stage
❑ Pull all ignition coils out of cylinder head using puller -T40039- .
❑ Removing and installing ⇒ page 248 .
19 - Inlet camshaft control valve 1 -N205-
❑ Removing and installing ⇒ page 66 .
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
