2 Turbocharger
Note
♦
Secure all hose connections with hose clips comparable to
production standard
♦
Hose connections and hoses for charge air system must be
free of oil and grease before assembly. The oil seal and seal‐
ing surface must be oiled lightly only for connector couplings .
♦
Charge air system must be free of leaks.
♦
Renew self-locking nuts.
♦
Hose clip pliers -VAS 6362- or hose clip pliers -V.A.G 1921-
are recommended for installation of spring-type clips.
♦
Fill turbocharger with engine oil at oil supply line connection.
♦
After installing turbocharger, run engine for about 1 minute at
idling and do not rev up immediately, this ensures that the tur‐
bocharger is fully primed with oil
♦
Observe rules for cleanliness ⇒ page 183 .
2.1 Assembly overview - turbocharger
Part I
Part II ⇒ page 194
Part III ⇒ page 195
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
192 Rep. gr.21 - Turbocharging/supercharging
