– Insert radiator mounting into lock carrier -2- at bottom -1-, do‐
ing so transversely to the direction of travel, and then turn it
90".
– When installing the radiator, make sure that the catches -1- of
the radiator mounting on the left and right at the top have en‐
gaged completely in the lock carrier.
– Insert top radiator mountings -1- on right and left into the
mounting on radiator -2- appropriately.
Observe instructions for hose connections with screw-type clips
⇒ page 184 .
– Install cowling ⇒ page 154 .
– Replenish coolant ⇒ page 133 .
Only for vehicles with air conditioning
– Install lock carrier ⇒ General body repairs, exterior; Rep. gr.
50 ; Lock carrier .
Continuation for all vehicles
Specified torques ⇒ page 152 .
Caution
The screw-type clips on the charge air lines must always be
tightened to 5.5 Nm. If the torque is too low or too high, the
charge air hose may slip off the charge air pipe during vehicle
operation.
Hose connections with screw-type clips ⇒ page 184 .
1.8 Checking charge air system for leaks
Special tools and workshop equipment required
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
1. Charge air system 189
