– Unscrew bolts -arrows- and remove oil pump.
– Pull chain tensioner back using assembly tool -T10118- and
have oil pump removed by a second mechanic.
Installing
• Specified torques ⇒ page 116 .
Installation is carried out analogously in the reverse order; note
the following:
– Before installing oil pump, check strainer in oil suction pipe and
oil galleries in upper part of sump for soiling.
– Check that both centring sleeves for centring oil pump are
present.
– Renew baffle plate.
Note
Plastic ribs that are permanently deformed during tightening are
located on the baffle plate. The plastic rips ensure that the baffle
plate rests without play and does not rattle. For this reason, the
baffle plate should always be replaced.
1.6 Removing and installing lower part of
sump
Special tools and workshop equipment required
♦ Used oil collection and extraction unit -V.A.G 1782-
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
120 Rep. gr.17 - Lubrication
