– Check adjustment again.
– Check markings on intermediate shaft sprocket/balancer shaft
-arrow-.
Note
For illustration purposes, the markings on intermediate shaft
sprocket/balancer shaft are shown with the chain removed.
Further assembly is basically the reverse of the dismantling se‐
quence. In the process, note the following:
– Install camshaft timing chain ⇒ page 76 .
– Install timing chain cover (bottom) ⇒ page 67 .
– Install timing chain cover (top) ⇒ page 67 .
– Install tensioner for poly V-belt ⇒ page 21 .
– Install poly V-belt ⇒ page 22 .
– Fit engine guard, if available ⇒ Body, front; Rep. gr. 50 ; En‐
gine guard .
2.10 Renewing balancer shaft for inlet cam‐
shaft
Special tools and workshop equipment required
♦ Puller -T10394-
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
84 Rep. gr.15 - Cylinder head, valve gear
