– Lubricate sealing surface of balance shaft -2- with gear oil.
– Fit oil seal -1- onto balance shaft.
• The marking „Luftseite“ („Outside“) -arrow- should be legible
from the outside.
Caution
Risk of damage to thread.
♦ The drive sprocket bolt has a left-hand thread.
– Apply thrust piece -T10353- to oil seal -1- and press into cyl‐
inder block as far as stop using bolt -2- (take care not to tilt oil
seal).
– Fit toothed belt for coolant pump ⇒ page 146 .
– Install short coolant pipe ⇒ page 141 .
– Replenish coolant ⇒ page 133 .
3.7 Removing and installing coolant pump
Removing
– Remove short coolant pipe ⇒ page 141 .
– Release long coolant pipe and lay aside ⇒ page 141 .
– Remove toothed belt for coolant pump ⇒ page 146 .
– Disconnect electrical connector -1- at throttle valve module -
J338- .
– Remove bolts -arrows- and detach throttle valve module -
J338- .
– Disconnect electrical connector -1- at coolant temperature
sender -G62- .
Note
-Item 2 and arrows- can be disregarded.
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
3. Parts of cooling system, engine side 149
