– Remove support for intake manifold (remove nut -2- and bolt
-1-).
– Disconnect electrical connector -1- at coolant temperature
sender -G62- .
– Detach retaining clip (press release tabs -arrows-).
Note
Place a cloth underneath to absorb escaping coolant.
– Remove coolant temperature sender -G62- -2-.
Installing
Installation is carried out in the reverse order. When installing,
note the following:
• Specified torque ⇒ page 144 .
Note
♦
Renew O-rings.
♦
Only demineralised / distilled water to standard VDE-0510
may be used for mixing. Tap water does not have the required
quality to ensure the coolant's function.
♦
Insert new coolant temperature sender -G62- immediately into
connection to avoid loss of coolant.
♦
Hose unions and air intake pipes/hoses must be free of oil and
grease when installing.
♦
Secure all hose connections with hose clips corresponding to
the series equipment ⇒ Electronic parts catalogue .
♦
In order to be able to securely attach the air ducts on their
connections, the screws of the used hose clips have to be
sprayed with penetrating spray before installing.
– Install intake manifold support ⇒ Rep. gr. 24 .
– Install throttle valve module -J338- ⇒ Rep. gr. 24 .
– Check coolant level ⇒ page 133 .
