– Unscrew union nut with union nut tool -3217- .
– Take fuel delivery unit out of the fuel tank.
Installing
Install in reverse order. In the process, note the following:
– Install fuel delivery unit so that mark on flange of fuel delivery
unit -1- is aligned with mark on fuel tank -arrows-.
3.4 Removing and installing fuel gauge
sender -G-
Removing
– Remove fuel tank ⇒ page 169 .
– Remove fuel delivery unit ⇒ page 172 .
– Free lines -2- and unclip fuel gauge sender -G- to side
-arrows-.
– Remove fuel gauge sender -G- -1- in -direction of arrow-.
– Release connectors on fuel gauge sender -G- .
Installing
– Insert fuel gauge sender -G- into guides on fuel pump and
press downwards until it engages.
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
3. Fuel tank 173
