1.3 Removing and installing centre silencer
Procedure
Special tools and workshop equipment required
♦ Engine and gearbox jack -V.A.G 1383 A-
– Support gearbox with engine and gearbox support -V.A.G
1383 A- .
– Release gearbox mounting from gearbox. To do so, loosen
bolts -1-.
– Remove cross member -2- for gearbox mounting -3-; to do so,
unscrew bolts -1-.
– Release double clip -2- to rear silencer; to do so, loosen se‐
curing nuts -1-.
– Release clip -2- to catalytic converter.
– Remove centre silencer downwards.
Installing
– Install in reverse order.
Amarok 2011 ➤
