– Turn tensioner in -direction of arrow- and withdraw locking tool
-T40098- .
– Release tensioner.
– Check that poly V-belt is properly seated.
– Start engine and check that poly V-belt runs properly.
1.4 Removing and installing ancillary brack‐
et
Special tools and workshop equipment required
♦ Drip tray for workshop hoist -VAS 6208-
♦ Locking tool -T40098-
Removing
– Drain coolant ⇒ page 133 .
Caution
If a used belt runs in the opposite direction when it is refitted,
this can cause breakage.
♦ Before removing, mark direction of rotation of poly V-belt
with chalk or felt-tipped pen for re-installation.
– To slacken poly V-belt turn tensioner in direction of -arrow-.
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
24 Rep. gr.13 - Crankshaft group
