5 - Roller tappet
6 - Fuel pressure regulating valve -N276-
7 - Bolts for high-pressure pump
❑ 20 Nm
8 - Connection for fuel pressurisation line to fuel rail
❑ Renew.
❑ 40 Nm
9 - Union nut of fuel pressurisation line
❑ 27 Nm
10 - Air flow control flaps (intake manifold flaps)
11 - Seal
❑ Renew.
12 - Intake manifold
❑ Removing and installing ⇒ page 213 .
13 - Vacuum unit for air flow control flaps (duct partition)
14 - Throttle valve module -J338- , throttle valve drive for electric throttle operation -G186-
❑ Throttle valve drive angle sender 1 for electric throttle -G187- and throttle valve drive angle sender 2 for
electric throttle -G188-
❑ After removing, installing or renewing throttle valve module -J338- it must be re-adapted to engine control
unit -J623- . See „Guided functions“.
❑ 7 Nm
15 - Bolts for intake manifold
❑ 9 Nm
16 - Intake manifold flap potentiometer -G336-
❑ After intake manifold flap potentiometer -G336- has been renewed, intake manifold flap potentiometer -
G336- must be adapted to engine control unit -J623- . Use vehicle diagnostic tester for this.
❑ Each time after intake manifold flap potentiometer -G336- or intake manifold has been removed or in‐
stalled, intake manifold flap potentiometer -G336- must be adapted to engine control unit -J623- . See
„Guided functions“.
17 - Fuel pressure sender -G247-
❑ 27 Nm
❑ Lubricate thread with clean engine oil
❑ Always renew connection and tighten to 25 Nm
2.8 Removing and installing intake manifold
After fuel rail has been removed or renewed, intake manifold flap
potentiometer -G336- must be adapted to engine control unit -
J623- . Use vehicle diagnostic tester for this.
Special tools and workshop equipment required
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
2. Injection system 213
