1.7 Removing and installing upper part of sump
Special tools and workshop
equipment required
♦ Assembly tool -T10118-
♦ Brake lining wear gauge -
VW 136-
♦ Torque wrench -V.A.G
1331-
♦ Silicone sealant -D 174 003
A2-
Removing
– Remove gearbox ⇒ Rep. gr. 34 .
– Remove oil pump ⇒ page 119 .
– Remove sealing flange on gearbox side ⇒ page 33 .
– Unscrew bolts -arrows-.
DANGER!
Injury risk! When removing upper part of sump, spring of chain
tensioner for oil pump drive jumps from upper part of sump to
lower timing chain cover. When removing upper part of sump,
do not grip between upper part of sump and lower timing chain
cover.
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
124 Rep. gr.17 - Lubrication
