Bracket for ancillaries - tightening sequence
– Fit bracket for ancillaries (first tighten bolt -4-).
– Tighten bolts in the sequence -1 … 5- in 3 stages as follows:
1. Tighten bolts hand tight.
2. Tighten bolts to 20 Nm.
3. Turn bolts 90° further.
Poly V-belt route with air conditioning system
1 - Vibration damper
2 - Guide roller
3 - Poly V-belt tensioning element
4 - Alternator
5 - Vane pump
6 - Air conditioner compressor
Poly V-belt route without air conditioner
1 - Vibration damper
2 - Guide roller
3 - Poly V-belt tensioning element
4 - Alternator
5 - Vane pump
1.2 Removing and installing tensioner for
poly V-belt
Special tools and workshop equipment required
Amarok 2011 ➤
4-cylinder injection engine (2.0 l direct injection engine, turbocharger) - Edition 02.2011
