4-2
Order
Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
8
9
Drive sprocket and exhaust
pipe/muffler removal
Air filter case
Carburetor assembly
Radiator assembly
Thermostatic valve assembly
Drive sprocket cover 1
Shift arm
Drive sprocket cover 2
Nut/Lock washer
Drive sprocket/Drive chain
Exhaust pipe/Muffler
Exhaust pipe gasket
Clutch cable
Spark plug caps
1
1
1
1/1
1/1
1/1
2
1
2
Remove the parts in the order below.
Refer to “AIR FILTER CASE” in CHAPTER 3.
Refer to “CARBURETOR” in CHAPTER 6.
Refer to “RADIATOR” in CHAPTER 5.
Refer to “THERMOSTATIC VALVE”
in CHAPTER 5.
For installation, reverse the removal
procedure.
20 Nm (2.0 mkg)
20 Nm (2.0 mkg)
24 Nm (2.4 mkg)
5 Nm (0.5 mkg)
70 Nm (7.0 mkg)
24 Nm (2.4 mkg)
12 Nm (1.2 mkg)
ENGINE ASSEMBLY
ENG
DRIVE SPROCKET AND EXHAUST PIPE/MUFFLER

Yamaha TDM850 1996 Specifications

General

Displacement	849 cc
Bore x Stroke	89.5 mm x 67.5 mm
Compression Ratio	10.5:1
Fuel System	Carburetor
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brakes	Dual disc
Rear Brakes	Single disc
Rear Tire	150/70-17
Fuel Capacity	20 liters
Seat Height	825 mm
Width	800 mm
Engine Type	4-stroke, parallel-twin
Ignition	Digital
