4-3
Order
Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
11
Engine removal
Starter motor
Vacuum hose
Breather hose
Bolt
Bolt
Bolt
Engine bracket (left)
Engine bracket (right)
Plug
Bolt
Bolt
Engine assembly
1
2
1
2
1
1
1
1
2
1
1
1
Remove the parts in the order below.
Place suitable stand under the frame and
engine.
Refer to “STARTER MOTOR” in CHAP-
TER 8.
 = 45 mm
 = 25 mm
 = 60 mm
 = 230 mm
 = 115 mm
Refer to “INSTALLATION”.
NOTE:
60 Nm (6.0 mkg)
10 Nm (1.0 mkg)
30 Nm (3.0 mkg)
30 Nm (3.0 mkg)
60 Nm (6.0 mkg)
89 Nm (8.9 mkg)
64 Nm (6.4 mkg)
30 Nm (3.0 mkg)
ENGINE ASSEMBLY
ENG
ENGINE ASSEMBLY

Yamaha TDM850 1996 Specifications

General

Displacement	849 cc
Bore x Stroke	89.5 mm x 67.5 mm
Compression Ratio	10.5:1
Fuel System	Carburetor
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brakes	Dual disc
Rear Brakes	Single disc
Rear Tire	150/70-17
Fuel Capacity	20 liters
Seat Height	825 mm
Width	800 mm
Engine Type	4-stroke, parallel-twin
Ignition	Digital
