8-34

SIGNAL SYSTEM

ELEC

POOR CONNECTION

Correct.

INCORRECT

Replace main switch.

MEETS

SPECIFICATION

Refer to “SWITCH INSPECTION”.

3. Main switch

CORRECT

S Check the entire signal system for connec-

tions.

Refer to “WIRING DIAGRAM”.

4. Wiring connection

CORRECT

INCORRECT

Replace handlebar switch (left).

Refer to “SWITCH INSPECTION”.

1. Horn switch

CORRECT

S Connect the pocket tester (DC 20 V) to the

horn lead.

2. Voltage

OUT OF SPECIFICATION

Wiring circuit from main switch to horn terminal

is faulty, repair.

Check condition of each circuit for signal sys-

tem. Refer to “SIGNAL SYSTEM CHECK”.

Tester (+) lead  Black/White lead

Tester (–) lead  Frame ground

S Turn the main switch to “ON”.

S Push the horn switch.

S Check for voltage (12 V) on the “Black/White”

lead at the horn terminal.

SIGNAL SYSTEM CHECK

1. Horn does not sound.
