7-46
STEERING HEAD
CHAS
Order
Job name/Part name Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
Lower bracket removal
Front wheel
Front fork
Handlebar
Main switch lead coupler
Starter cable holder
Cable guide
Horn/Horn lead coupler
Brake hose holder
Steering stem nut
Plate washer
Upper bracket
Special washer
Ring nut (upper)
1
1
1
1/1
1
1
1
1
1
1
Remove the parts in the order below.
Refer to “FRONT WHEEL AND
BRAKE DISC”.
Refer to “FRONT FORK”.
Refer to “HANDLEBAR”.
Disconnect
Disconnect
Refer to “REMOVAL”.
7 Nm (0.7 mkg)
108 Nm (10.8 mkg)
10 Nm (1.0 mkg)
48 Nm (4.8 mkg)
16 Nm (1.6 mkg)
1st
7 Nm (0.7 mkg)
2 nd
STEERING HEAD
LOWER BRACKET
