Yamaha TDM850 1996 User Manual

22
1
3
5
7
9
2
4
8
6
24 25
2321
19 2018
16 1715
1413
11 12
10
GEN
INFO
SPEC
ENG
CARB
ELECCHAS
COOL
INSP
ADJ
TRBL
SHTG
EB003000
ILLUSTRATED SYMBOLS
Illustrated symbols 1 to 9 are printed on top
right of each page and indicate the subject of each
chapter.
1
General information
2
Specifications
3
Periodic inspections and adjustments
4
Engine
5
Cooling system
6
Carburetion
7
Chassis
8
Electrical
9
Troubleshooting
Illustrated symbols
10
to
17
are used to identify
the specifications appearing in the text.
10
Can be serviced with engine mounted
11
Filling fluid
12
Lubricant
13
Special tool
14
Torque
15
Wear limit, clearance
16
Engine speed
17
Ω, V, A
Illustrated symbols
18
to
23
in the exploded dia-
grams indicate the types of lubricants and lubrica-
tion points.
18
Apply engine oil
19
Apply gear oil
20
Apply molybdenum disulfide oil
21
Apply wheel bearing grease
22
Apply lightweight lithium soap base grease
23
Apply molybdenum disulfide grease
Illustrated symbols
24
to
25
in the exploded dia-
grams indicate where to apply a locking agent
24
and when to install new parts
25
.
24
Apply locking agent (LOCTITE

)
25
Replace

Yamaha TDM850 1996 Specifications

General

Displacement	849 cc
Bore x Stroke	89.5 mm x 67.5 mm
Compression Ratio	10.5:1
Fuel System	Carburetor
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brakes	Dual disc
Rear Brakes	Single disc
Rear Tire	150/70-17
Fuel Capacity	20 liters
Seat Height	825 mm
Width	800 mm
Engine Type	4-stroke, parallel-twin
Ignition	Digital
