8-5
IGNITION SYSTEM
ELEC
NOTE:
Refer to “SWITCH INSPECTION”.
1. Fuse (main and ignition)
Replace fuse(s).
NO CONTINUITY
S Check the battery condition.
Refer to “BATTERY INSPECTION” in CHAP-
TER 3.
2. Battery
CONTINUITY
Open-circuit voltage:
12.8 V or more at 20_C
:
S Clean battery terminals.
S Recharge or replace the battery.
INCORRECT
CORRECT
TROUBLESHOOTING
IF IGNITION SYSTEM SHOULD BECOME INOPERATIVE (NO SPARK OR INTERMITTENT SPARK)
Procedure
Check:
1. Fuse (main and ignition)
2. Battery
3. Spark plug
4. Ignition spark gap
5. Spark plug cap resistance
6. Ignition coil resistance
7. Pickup coil resistance
8. Main switch
9. Engine stop switch
10. Neutral switch
11. Sidestand switch
12. Wiring connection
(entire ignition system)
S Remove the following parts before troubleshoot-
ing.
1) Seat
2) Side cowlings
3) Side covers
4) Fuel tank
5) Air filter case
S Use the following special tool(s) in this trouble-
shooting.
Ignition checker:
90890-06754
Pocket tester:
90890-03112

Yamaha TDM850 1996 Specifications

General

Displacement	849 cc
Bore x Stroke	89.5 mm x 67.5 mm
Compression Ratio	10.5:1
Fuel System	Carburetor
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brakes	Dual disc
Rear Brakes	Single disc
Rear Tire	150/70-17
Fuel Capacity	20 liters
Seat Height	825 mm
Width	800 mm
Engine Type	4-stroke, parallel-twin
Ignition	Digital
