Yamaha TDM850 1996 User Manual

2-11
MAINTENANCE SPECIFICATIONS
SPEC
CHASSIS
Item Standard Limit
Steering system:
Steering bearing type
Angular bearing

Front suspension:
Front fork travel
Fork spring free length
Spring rate (K1)
Stroke (K1)
Optional spring
Oil capacity (per fork tube)
Oil level
Oil grade
149 mm
505 mm
6.4 N/mm (0.64 kg/mm)
0  149 mm
No
0.515 L
130 mm
Fork oil 01 or equivalent

500 mm






Rear suspension:
Shock absorber travel
Spring free length (K1/K2)
Fitting length (K1/K2)
Spring rate (K1/K2)
Stroke (K1/K2)
Optional spring
47 mm
144 mm/69 mm
136 mm/65 mm
260 N/mm (26.0 kg/mm)/182 N/mm
(18.2 kg/mm)
0  30/30  47 mm
No






Swingarm:
Free play limit end
side


1 mm
0.3 mm
Front wheel:
Type
Rim size
Rim material
Rim runout limit radial
lateral
Cast wheel
18  MT3.00
Aluminum





1 mm
0.5 mm
Rear wheel:
Type
Rim size
Rim material
Rim runout limit radial
lateral
Cast wheel
17  MT4.00
Aluminum





1 mm
0.5 mm
Drive chain:
Type/manufacturer
No. of links
Chain slack
525HV/DAIDO
114
40  50 mm




Yamaha TDM850 1996 Specifications

General

Displacement	849 cc
Bore x Stroke	89.5 mm x 67.5 mm
Compression Ratio	10.5:1
Fuel System	Carburetor
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Suspension	Monoshock
Front Brakes	Dual disc
Rear Brakes	Single disc
Rear Tire	150/70-17
Fuel Capacity	20 liters
Seat Height	825 mm
Width	800 mm
Engine Type	4-stroke, parallel-twin
Ignition	Digital
