MAINTENANCE
27080 Issue 1 Sept 98 7--17
13. Print Head Cleaning
Theprintermustbeshutdown. Fittheprintheadintothemaintenance
holster.
(1) Wash down the gutter. Dry the wet
areas with lint--free tissue.
(2) If required, also wash down the
deflector plates, avoiding wetting the
Charge Electrode.
If the Charge Electrode needs cleaning:
(3) Undo the securing screw and pull the
electrode gently away from its
mounting.
(4) Weta pieceoftissuewithwashand
draw it through the slot in the
ChargeElectrode. Any inkresidue
in the slot will stain the tissue.
Wash the rest of the electrode.
(5) Draw some dry tissue through the slot and dry the rest of the
electrode. Ensure that no traces of tissue remain in the slot.
(6) Refit the Charge Electrode and tighten the securing screw.
Refit the print head into its holster.
14. Obtain a Print Sample
Obtainaprintsample(instructionsaregivenonpg.A--11)andcheckthe
quality of the print. Keep this sample and attach it to themaintenance
sheet.
15. Airdryer Service (If fitted)
For the relevant information on 2000/4000 hour service, refer to the
AppendixB:AirDrivenAirdryer,or,AppendixB:CompressorDriven
Airdryer accompanying the Airdryer.
Deflector
Plates
Charge
Electrode
Gutter
TP3278--6
