6-11
Status Bar Codes The status bar provides up to four status items:
• The first field in the status bar is a message field.
• Tag: Indicates if a configuration file (filename.MFL) was loaded
into the EA memory.
Other options include the following:
(Uploaded Data) indicates that the current configuration
information was uploaded from a transmitter.
(Blank) indicates configuration information has not been
loaded in from a transmitter or from a configuration file.
• Security: Indicates security status: disabled, low, high,
medium, or off-line.
• HART field indicates communication status: Idle or Busy.
Hot Keys An underline character in a menu selection indicates the Hot Key for
that selection. Press the character to select that menu item.
Path Name Convention In this section, each heading also identifies the path name. For
example, consider the following heading:
M
aintenance
A
nalog Output
R
ange Values...
This indicates that the menu is found under the M
aintenance, Analog
Output, R
ange Values... path. This menu can be accessed in multiple
ways. Three examples are shown:
• Select M
aintenance, select Analog Output, select Range Values...
• Press Alt-M, A, R.
• Press Alt-M, use the arrow keys to highlight Analog Output and
press
UHWXUQ , use the arrow keys to highlight Range Values and
press
UHWXUQ .
Procedure Convention
Rather than explaining all of the possible ways to access a particular
screen, procedures in this manual use the term “Select” to indicate
there are multiple ways to select an option. For example, the first step
in the Sensor Trim procedure is illustrated below.
1. Select M
aintenance, Sensor Trim to display the Sensor Trim Select
screen.
Cancel Buttons All EA screens that allow data entry or transmitter action contain a
Cancel button. Select Cancel to exit the screen without making any
changes.
Fast Keys Certain menu selections have fast keys assigned, and they are
indicated in the menu structure. For example, pressing Ctrl + O is the
fast way to open a configuration file.
