Rosemount Model 1195/ProPlate/Mass ProPlate
6-36
Transmitter HART Output
Communication Configuration
The communication configuration screen sets the number of response
preambles for transmitter to EA communication. The valid range for
this setting is 2–20 preambles. The default setting is five.
Typically, this value if left at five. Increase this value only if the
transmitter is installed in an electrically noisy environment.
Figure 6-32.
Connect Screen.
NOTE
Dynamic Variables
and Current (HART
Cmd 3) required if
connection
to a HART Tri-Loop.
Figure 6-33.
Communication Configuration Screen.
