Rosemount Model 1195/ProPlate/Mass ProPlate
3-4
Environmental
Considerations
Mount the ProPlate to minimize ambient temperature changes.
Section : Specifications and Reference Data lists the ProPlate
temperature operating limits. Mount the ProPlate electronics to avoid
vibration and mechanical shock, and to avoid external contact with
corrosive materials.
Access Requirements When choosing an installation location and position, consider the need
for access to the ProPlate.
Process Flange Orientation Orient the process flanges on a remote mounted ProPlate so that
process connections can be made. For safety reasons, orient the drain/vent
valves so that process fluid is directed away from technicians when the valves
are used. In addition, consider the possible need for a testing or calibration
input.
Housing Rotation The electronics housing may be rotated up to 90 degrees (left or right)
to improve field access to the two compartments or to better view the
optional LCD meter. To rotate the housing, release the housing rotation
set screw and turn the housing not more than 90 degrees.
NOTE
Do not rotate the housing greater than 90 degrees. Rotating the housing
greater than 90 degrees will damage the sensor module and void the
warranty.
Terminal Side of the
Electronics Housing
Wiring connections are made through the conduit openings on the top
side of the housing. The field terminal side is marked on the electronics
housing. Mount the ProPlate so that the terminal side is accessible. A
0.75’’ clearance is required for cover removal. Use a conduit plug on the
unused side of the conduit opening.
Circuit Side of the
Electronics Housing
The circuit compartment should not routinely need to be opened when
the unit is in service; however, provide 0.75-in. clearance if possible to
allow access. A 3-in. clearance is required for cover removal if a meter
is installed.
Exterior of the
Electronics Housing
The integral span and zero push-buttons are located under the
certifications plate on the top of the ProPlate. The plate will be blank if
no certifications are ordered.
Cover Installations Always install the electronics housing covers metal-to-metal to ensure a
proper seal.
