Rosemount Model 1195/ProPlate/Mass ProPlate
6-8
Menu Categories The Mass ProPlate menu bar identifies seven menu categories:
F
ile
The File category contains screens for reading and writing Mass
ProPlate configuration files.
S
etup
The Setup category contains Mass ProPlate screens which are only
available when the Engineering Assistant is “disconnected.” These
screens also determine the contents of a configuration file, and
are used to define a Compensated Flow measurement solution.
T
ransmitter
Except for “Disconnect” and “Recv Config,” any changes made in this
series of screens occurs immediately to the connected transmitter.
M
aintenance
The Maintenance screens perform typical transmitter maintenance
functions, including set the analog output, set range values, output
trim, and sensor trim. Any changes made in this series of screens
occurs immediately to the connected transmitter.
D
iagnostics
The Diagnostic screens provide troubleshooting and diagnostic screens.
V
iew
The View selections determine whether the toolbar and the status
bar are displayed.
H
elp
The Help selection identifies the current EA software revision.
PROCEDURE OUTLINES These procedures only outline the major steps for each procedure. Refer
to the individual screen explanations for additional information.
Bench Configuration
(Standard)
1. (If needed) Select Transmitter, Disconnect to switch to
disconnect mode.
2. (Optional) If a configuration file is already created, select F
ile,
O
pen Config to retrieve those configuration settings.
3. Select S
etup, Units..., then verify the units parameters.
4. Select S
etup, Damping..., then verify the damping parameters.
5. Select S
etup, Device Info..., then fill in the device information
screen.
6. Select Setup, C
ompensated Flow..., then follow the series of three
flow configuration screens, filling in the information for your flow
application. When finished, the following screen is displayed:
