A-17

Figure A-10.

Bench Hook-up

(4–20 mA Flowmeters).

Figure A-11.

Field Hook-up (4–20 mA Flowmeters).

COMMUNICATOR KEYS The keys of the HART Commuincator include action, function,

alphanumeric, and shift keys























Current Meter

24 V dc

Supply



250

Signal point may be grounded at any point

or left ungrounded.

CAUTION

Do not use inductive-based

transient protectors.























Power



Supply

Current

Meter



250

Default Chapter3
