10-7
Remote Mount
–40 to 850°F (–40 to 454°C).
Damping
Analog output response to a step input change is user selectable from
0 to 36 seconds for one time constant. This software damping is in
addition to sensor module response time.
Turn-on Time
Performance within specification less than two seconds after power is
applied.
Humidity Limits
0–100% relative humidity.
Performance
Specifications
Stability
0.25% of URL for 5 years.
Time Response (Electronics Only)
Dead time (Td): 45 milliseconds (nominal).
Time Constant (Tc): 55 milliseconds.
Update Rate: 20 times per sec. (minimum).
Vibration Effect
Less than 0.1% of URL per g when tested from 15 to 2000 Hz in any
axis relative to pipe-mounted process conditions.
Power Supply Effect
Less than 0.005% of calibrated span per volt.
RFI Effect
0.1% of span from 20 to 1000 MHz and for field strength up to 30 V/m.
Ambient Temperature Effect Per 50°F (28°C)
(0.0188% URL + 0.0938% span).
Spans from 1:1 to 10:1.
(0.038% URL + 0.188% span).
Spans from 10:1 to 100:1.
For Range 1:
(0.18% URL + 0.375% span).
Static Pressure Effect
Zero error (can be calibrated out at line pressure).
0.1% of URL/1,000 psi (6.9MPa) for line pressures from 0 to 2,000 psi
(0 to 13.7MPa).
0.2% of URL/1,000 psi (6.9MPa) for line pressure above 2,000 psi
(13.7MPa).
Range 1: +0.25% of URL/1,000 psi (6.9MPa).
