Section
7-1
7 LCD Meter Options
PROPLATE FLOWMETER Options available with the ProPlate can ease installation and enhance
the security of control systems. These options include the integral zero
and span adjustments, LCD meters, mounting brackets, custom
configurations, optional bolt materials, and the transient protection
terminal block.
SAFETY MESSAGES Procedures and instructions in this section may require special
precautions to ensure the safety of the personnel performing the
operations. Information that raises potential safety issues is indicated
by a warning symbol ( ). Refer to the following safety messages before
performing an operation preceded by this symbol.
LCD METER The LCD meter provides local indication of the output, and abbreviated
diagnostic messages governing flowmeter operation. The meter is
located on the electronics module side of the flowmeter, maintaining
direct access to the signal terminals. An extended cover is required to
accommodate the meter.
The meter features a two-line display that accommodates five digits for
reporting the process variable on the top line, and six characters for
displaying engineering units on the bottom line
(1)
. And in addition to
units of pressure, the new LCD meter is capable of displaying flow and
volume units. The meter uses both lines to display diagnostic messages.
You can configure the meter to display the following information:
• Engineering Units
• Percent of Range
• Alternating between any two of the above
Explosions could result in death or serious injury:
• Do not remove the transmitter cover in explosive atmospheres when the circuit
is alive.
• Before connecting a HART-based communicator in an explosive atmosphere,
make sure the instruments in the loop are installed in accordance with
intrinsically safe or non-incendive field wiring practices.
• Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications.
• Both transmitter covers must be fully engaged to meet explosion-proof
requirements.
Electrical shock can result in death or serious injury.
• Avoid contact with the leads and the terminals.
(1) Previous versions differ slightly.
