Rosemount Model 1195/ProPlate/Mass ProPlate
6-26
Setup Compensated Flow (Natural Gas Procedure)
1. Select G
as.
2. Select Natural Gas.
3. Select 1195 Integral Orifice.
4. Select Next.
5. Select the desired characterization method, then select Next.
• If the Detail Method is selected, turn to page 6-27.
• If the Gross 1 Method is selected, turn to page 6-27.
• If the Gross 2 Method is selected, turn to page 6-28.
Figure 6-19.
Flow Setup Screen
(Natural Gas Configuration).
Figure 6-20. Flow Setup Screen
(Natural Gas Applications).
To Next Page
