Rosemount Model 1195/ProPlate/Mass ProPlate
6-28
Volumetric Gross Dry Heating Value at 60°F, 14.73 psia
477–1150 BTU/SCF.
C
O2 (carbon dioxide) mole percent
0–30 percent.
H2
(hydrogen) mole percent (optional)
0–10 percent.
CO
(carbon monoxide) mole percent (optional)
0–3 percent.
8. Enter a value into each of the desired Natural Gas component
fields.
9. After all the percentages are entered, Select Next.
Gross Characterization Method #2
The gross characterization method 2 requires the entry of real gas
specific gravity, value, CO2 mole percent, and N2 mole percent, also
allows entry of H2 mole percent and CO mole percent. H2 and CO are
typically zero for natural gas applications.
The valid ranges for gross characterization method 2 components are:
R
eal gas relative density (specific gravity) at 60°F, 14.73 psia
0.554–0.87.
C
O2 (carbon dioxide) mole percent
0–30 percent.
N2
(hydrogen) mole percent
0–50 percent.
H2
(hydrogen) mole percent (optional)
0–10 percent.
Figure 6-22.
Natural Gas Setup Screen
(Gross Characterization Method 1).
