7-5
FAIL ELECT
The flowmeter electronics board is malfunctioning due to an internal
fault. Some of the FAIL ELECT errors are user-repairable. Use a Model
275 HART Communicator to diagnose the error and determine if it is
repairable. Any error message that ends in “FACTORY” is not
repairable. In cases of non user-repairable errors, you must replace the
electronics board. See Remove the Electronics Board on page 9-3, or
contact Rosemount Customer Central at 800-999-9307 if you need
assistance.
FAIL CONFIG
A memory fault has been detected in a location that could effect
flowmeter operation, and is user-accessible. To correct this problem, use
a Model 275 HART Communicator to interrogate and reconfigure the
appropriate portion of the flowmeter memory. Contact Dieterich
Standard Inc. at 303-530-9600 if you need assistance.
Warnings
Warnings appear on the LCD meter display to alert you of
user-repairable problems with the flowmeter, or current flowmeter
operations. Warnings appear alternately with other flowmeter
information until the warning condition is corrected or the flowmeter
completes the operation that warrants the warning message.
NOTE
The warning messages on previous versions of the LCD meter may vary
slightly from those listed here, but they represent the same warning.
FPRES LIMIT
The process variable read by the flowmeter is outside of
sensor range limits.
P/T LIMIT
The secondary or tertiary temperature variable read by the electronics
is outside of flowmeter range.
CURR FIXED
The flowmeter is in multidrop mode. The analog output is not tracking
pressure changes.
CURR SATURD
The pressure read by the module is outside of the specified range, and
the analog output has been driven to saturation levels (see the tables
on page 5-2).
LOOP TEST
A loop test is in progress. During a loop test or 4–20 mA trim, the
analog output is set to a fixed value. The meter display alternates
between the current selected in milliamps and “LOOP TEST.”
