Rosemount Model 1195/ProPlate/Mass ProPlate
5-24
NOTE
The HART Communicator Model 275 requires you to use the Utility
Menu to perform an auto poll. This menu is available from the Main
Menu of the HART Communicator. Press the left arrow to move
from the On-line Menu to the Main Menu. Press 4 from the Main
Menu to access the Utility Menu.
MASS PROPLATE
FLOWMETER
Safety Messages
Procedures and instructions in this section may require special
precautions to ensure the safety of the personnel performing the
operations. Information that raises potential safety issues is indicated
by a warning symbol ( ). Refer to the following safety messages before
performing an operation preceded by this symbol.
Explosions could result in death or serious injury:
• Do not remove the transmitter cover in explosive atmospheres when the circuit
is alive.
• Before connecting a HART-based communicator in an explosive atmosphere,
make sure the instruments in the loop are installed in accordance with
intrinsically safe or non-incendive field wiring practices.
• Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications.
• Both transmitter covers must be fully engaged to meet explosion-proof
requirements.
• The unused conduit opening on the electronics housing must be plugged and
sealed to meet explosion-proof requirements.
Failure to follow these installation guidelines could result in death or serious injury:
• Make sure only qualified personnel perform the installation.
For explosion-proof installations, wiring connections must be made in accordance with
Rosemount drawing 03095-1025 or 03095-1024.
For intrinsically safe installations, wiring connections must be made in accordance with
ANSI/ISA-RP12.6, and Rosemount drawings 03095-1020 or 03095-102s1.
For ALL installations, wiring connections must be made in accordance with local or
national installation codes such as the NEC NFPA 70.
