1 Introduction
The Model 1195 Integral Flow Orifice Assembly is a primary flow
element. It is designed to create a differential pressure proportional to
flow in a 1/2 in. (15 mm), 1 in. (25 mm), or 1 1/2 in. (40 mm) process
pipe. ProPlate
®
and Mass ProPlate
®
are integrated flow meters
combining the 1195 Integral Orifice with either a 3051CD Smart DP
Transmitter or 3095MV MultiVariable Mass Flow Transmitter and
RTD Temperature Measurement.
For the Model 1195, this process is measured by a secondary element,
such as one of the Rosemount differential pressure transmitters listed
in Table 1-1. The Model 1195, ProPlate and Mass ProPlate measure
flow rates ranging from 0.001 GPM (0.004
O
/min) to 95 GPM (360
O
/min)
in clean liquids, or from 0.25 ft
3
/hr (0.007 m
3
/hr) to 22,000 ft
3
/hr (623
m
3
/hr) in clean gas or steam.
NOTE
This device is designed to measure forward flow.
Table 1-1.
Rosemount Transmitters
for use with the Model 1195.
SAFETY MESSAGES Procedures and instructions in this manual may require special
precautions to ensure the safety of the personnel performing the
operations. Refer to the safety messages, listed at the beginning of each
section, before performing any operations.
HOW TO USE THIS
MANUAL
This product manual provides installation, configuration,
calibration, troubleshooting, and maintenance instructions
for the Model 1195, ProPlate, and Mass ProPlate Mass Flowmeter.
This section contains an explanation of each section of the manual, a
flowchart for using the manual, and an installation checklist.
Section 2: Hardware Installation explains initial inspection,
operating limitations, and in what location and orientation to install
the Model 1195, ProPlate, or Mass ProPlate models for liquid, gas or
steam service. Also explains how to install the remote mounted Model
1195, ProPlate, and Mass ProPlate electronics for liquid, gas or steam
service.
Section 3: Field Wiring and Electrical Considerations provides
electrical considerations and field wiring diagrams to wire the ProPlate
and Mass ProPlate.
Model 1151DP Differential Pressure Transmitter
Model 1151DP Square Root Flow Transmitter
Model 1151HP High Pressure Differential Transmitter
Model 1151 Low-Power Pressure Transmitter
Model 1151DP Smart Pressure Transmitter
Model 3051C Smart Differential Pressure Transmitter
Model 2024D Differential Pressure Transmitter
Model 3095 MV
™
Multivariable
™
Mass Flow Transmitter
