9 - 32
9.2 C Controller Setting Utility
9.2.5 Operating Module monitor screen
9
UTILITY OPERATION
Remark
The information of the "System information" screen is based on the time when the
"System information" screen is opened.
To update the information, close and reopen the "System information" screen.
Table9.14 Explanation of System information screen (Continued)
Item Description
Reference
section
System configuration
Displays the information of the modules that comprise the C Controller
system.
Double-clicking a module (or selecting a module and pressing the [Enter]
key) closes the system information screen and displays the module
monitor screen for the module.
In a single CPU system, however, selection of CPU module is not
allowed.
Slot
Displays the "Slot No." of the module, the stage No. of the base unit
where the module is installed, and the installation position within the base
unit.
Type
Displays the type of the module.
(Display range: "Empty", "Input", "Hi. input", "Output", "I/O mix", "Intelli.",
"Interrupt", "CPU")
Series
Displays the series name of the module.
(Display range: "Q" (fixed))
Model name Displays the model name of the module.
Points
Displays the I/O points of the module.
(Display range: 0, 16, 32, 48, 64, 128, 256, 512, 1024)
Start I/O No.
Displays the start I/O No. of the module.
(Display range: 0000 to 0FF0, 3E00 to 3E30)
Control CPU
Displays the CPU No. of the control CPU of the module.
(Display range: "No. 1" to "No. 4")
Serial No. Displays the serial No. of the module.
Ver. Displays the function version of the module.
button
Saves the displayed C Controller system information into the system
information save file.
This section
(4)
button
Selecting a module and pressing the button closes the "System
information" screen and displays the module monitor screen for the
information of the selected module.
This section
(2)
button
Closes the system information screen.
Save system information
Select
Select
Close
